| Nama Wahi | NL3224AC35-01 |
| Waitohu | NLT |
| Rahi | 5.5 |
| Taupānga | CNS |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | 220 |
| CR | 85:1 |
| Nga Tae | Full color |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | NEC |
| panel model | NL3224AC35-01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.5 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 111.36×83.52 mm |
| outline | 134×110 mm |
| surface | Antiglare |
| brightness | 220 cd/m² (Typ.) |
| contrast ratio | 85:1 (Typ.) |
| display colors | Full color , CIE193150% |
| response time | 16/44 (Typ.)(Tr/Td) |
| viewing angle | 45/45/30/15 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB, 30 pins |
| input voltage | 9.5V (Typ.) |
| application | CNS |
