| Nama Wahi | LQ101K5DZ01 |
| Waitohu | SHARP |
| Rahi | 10.1 |
| Taupānga | CNS |
| Whakatau | 1280×422 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 2000:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ101K5DZ01 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.1 inch |
| resolution | 1280(RGB)×422 |
| display mode | ASV, Normally Black, Transmissive |
| active area | 242.88×80.07 mm |
| outline | 259.7×96.5 mm |
| surface | Antiglare, Reflection 1.5% (Typ.) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 2000:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC) |
| response time | 15/5 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 8-bit), 68 pins |
| input voltage | 3.3V (Typ.) |
| application | CNS |
