| Nama Wahi | AV080WSM-NW3 |
| Waitohu | BOE |
| Rahi | 8.0 |
| Taupānga | CNS |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 600 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | BOE |
| panel model | AV080WSM-NW3 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | ADS, Normally Black, Transmissive |
| active area | 176.64×99.36 mm |
| outline | 192.8×116.9×7.1 mm |
| surface | |
| brightness | 600 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193150% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S10PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| input voltage | 3.3/11.5/24/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| application | CNS |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| AV080WSM-NW3 | BOE | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LA080WV8-SL01 | LG Display | 8.0 | 800×480 |
| LM64P122 | SHARP | 8.0 | 640×480 |
| LT080EE04100 | TOSHIBA | 8.0 | 1600×768 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| A070FW03 V1 | AUO | 7.0 | 480×234 |
| A070VW01 V1 | AUO | 7.0 | 800×480 |
| G121S1-L01 | Innolux | 12.1 | 800×600 |
| HSD050I9W1-A00 | HannStar | 5.0 | 480×272 |
| LB070WV7-TD01 | LG Display | 7.0 | 800×480 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ070Y5DR04 | SHARP | 7.0 | 800×480 |
| LQ7BW566AH | SHARP | 7.0 | 480×234 |
| ND078-101A1 | SEBO | 7.8 | 1280×400 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
