LG Display LB070WQ4-TM01 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com

LB070WQ4-TM01


Waitohu
LG Display
Rahi
7.0
Taupānga
CNS
Whakatau
480×234
Te tito
LCM
Tirohanga
450
CR
400:1
Nga Tae
Full color
Whakamuri
CCFL
Atanga
Analog
In Stock
14922
Whakatakotoranga

Nama Wahi LB070WQ4-TM01
WaitohuLG Display
Rahi7.0
TaupāngaCNS
Whakatau480×234
Te titoLCM
Tirohanga450
CR400:1
Nga TaeFull color
WhakamuriCCFL
AtangaAnalog
panel brandLG.Philips LCD
panel modelLB070WQ4-TM01
panel type a-Si TFT-LCD , LCM
panel size7.0 inch
resolution480(RGB)×234
display modeTN, Normally White, Transmissive
active area156.24×82.368 mm
outline167×93×7.8 mm
surfaceAntiglare
brightness450 cd/m² (Typ.)
contrast ratio400:1 (Typ.)
display colorsFull color , CIE193145%
response time50/75 (Max.)(Tr/Td)
viewing angle60/60/50/60 (Typ.)(CR≥10)(L/R/U/D)
lamp type1 pcsCCFLWithout Driver
signal interfaceTFT Specific Analog RGB, 30 pins
input voltage3.3/5.0/18.5/-12.0V (Typ.)(VDD1/VDD2/VGH/VGL)
applicationCNS
Tauira Whanau
LB070WQ4-TM01 LG Display 7.0 480×234
LB070WV1-TD01 LG Display 7.0 800×480
LB070WV1-TD04 LG Display 7.0 800×480
LB070WV1-TD12 LG Display 7.0 800×480
LB070WV1-TD17 LG Display 7.0 800×480
LB070WV3-SD01 LG Display 7.0 800×480
LB070WV3-SD02 LG Display 7.0 800×480
LB070WV6-TD06 LG Display 7.0 800×480
LB070WV6-TD08 LG Display 7.0 800×480
LB070WV7-TL01 LG Display 7.0 800×480
