| Nama Wahi | CLAA080MB0DCW |
| Waitohu | CPT |
| Rahi | 8.0 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | CPT |
| panel model | CLAA080MB0DCW |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 183×141×6.6 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit), CIE193150% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S8PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 60 pins |
| input voltage | 3.3/9.6/18/-6V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | DPF |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| CLAA089NA0FCW | CPT | 8.9 | 1024×600 |
| A070SN02 V0 | AUO | 7.0 | 800×600 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| HSD084ISN1-A01 | HannStar | 8.4 | 800×600 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| HSD101PFW2-B01 | HannStar | 10.1 | 1024×600 |
| LB070WV1-TD17 | LG Display | 7.0 | 800×480 |
| LB104S02-TD01 | LG Display | 10.4 | 800×600 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
| TM080SV-04L01 | SANYO | 8.0 | 800×600 |
