| Nama Wahi | CLAA088WA01XN |
| Waitohu | CPT |
| Rahi | 8.8 |
| Taupānga | CNS |
| Whakatau | 1280×480 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | CPT |
| panel model | CLAA088WA01XN |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.8 inch |
| resolution | 1280(RGB)×480 , DVGA |
| display mode | HFFS, Normally Black, Transmissive |
| active area | 209.28×78.48 mm |
| outline | 229.6×97.3×6.3 mm |
| surface | Antiglare (Haze 25%) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193170% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S14PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 60 pins |
| input voltage | 3.3/13.0/20/-6.0V (Typ.)(DVDD/AVDD/IGH/IGL) |
| application | CNS |
