| Nama Wahi | PD040QX1 |
| Waitohu | E Ink |
| Rahi | 4.0 |
| Taupānga | CNS |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 400:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | PVI |
| panel model | PD040QX1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.0 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 81.12×60.84 mm |
| outline | 93×73.5 mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 15/25 (Typ.)(Tr/Td) |
| viewing angle | 80/80/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 4S2PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit), 60 pins |
| input voltage | 3.3/3.3/9.6/17.0/-8.0V (Typ.)(VCC1/VCC2/VDDA/VCG/VEE) |
| application | CNS |
