| Nama Wahi | C070VW02 V1 |
| Waitohu | AUO |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 300:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AUO |
| panel model | C070VW02 V1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 152.4×91.44 mm |
| outline | 170.8×107.95×21.5 mm |
| surface | Antiglare (Haze 40%), Hard coating (3H) |
| brightness | 350 cd/m² (Min.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 20/30 (Max.)(Tr/Td) |
| viewing angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 4S4PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 98 pins |
| input voltage | 3.3/9.8/15/-7V (Typ.)(VDD/AVDD/VGH/VGL) |
| rohs: | |
| application | CNS |
| C070VAN01.1 | AUO | 7.0 | 800×480 |
| C070VTN02.0 | AUO | 7.0 | 800×480 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| C070VVN03.3 | AUO | 7.0 | 800×480 |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| C070VW04 V2 | AUO | 7.0 | 800×480 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| CLAA070LC05CW | CPT | 7.0 | 800×480 |
| L5F30705T10 | Epson | 5.0 | 400×240 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LQ058Y5DG30A | SHARP | 5.8 | 800×480 |
| LQ088H9DR01U | SHARP | 8.8 | 640×240 |
| LQ6BW506 | SHARP | 5.8 | 400×234 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| PW100XS5 | E Ink | 10.0 | 640×468 |
