| Nama Wahi | PW100XS5 |
| Waitohu | E Ink |
| Rahi | 10.0 |
| Taupānga | CNS |
| Whakatau | 640×468 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 350:1 |
| Nga Tae | Full color |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | PVI |
| panel model | PW100XS5 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.0 inch |
| resolution | 640(RGB)×468 |
| display mode | TN, Normally White, Transmissive |
| active area | 216×129.636 mm |
| outline | 235×145.8×6.4 mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) |
| display colors | Full color |
| response time | 15/25 (Typ.)(Tr/Td) |
| viewing angle | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 32 pins |
| input voltage | 3.3/5.0/12.5/24.0/-8.0V (Typ.)(VCC/VDD2/VDD1/VGH/VEE) |
| application | CNS |
| C070FW02 V2 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LA070WV6-SL02 | LG Display | 7.0 | 800×480 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
