| Nama Wahi | CLAA080LG02AW |
| Waitohu | CPT |
| Rahi | 8.0 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 550 |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | CPT |
| panel model | CLAA080LG02AW |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 175.2×105.12 mm |
| outline | 186.5×117.22×6.73 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 550 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 262K (6-bit), CIE193171% |
| response time | 12 (Typ.)(Tr+Td) |
| viewing angle | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 9S4PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 60 pins |
| input voltage | 3.3/12.0/18.0/-6.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| application | CNS |
