| Nama Wahi | A070FW01 |
| Waitohu | AUO |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 480×234 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 150:1 |
| Nga Tae | |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | AU Optronics |
| panel model | A070FW01 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 480(RGB)×234 |
| display mode | TN, Normally White, Transmissive |
| active area | 154.08×86.58 mm |
| outline | 166×100 mm |
| surface | |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 150:1 (Typ.) |
| display colors | |
| response time | 25/30 (Typ.)(Tr/Td) |
| viewing angle | 60/60/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 26 pins |
| input voltage | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | CNS |
| A070FW01 | AUO | 7.0 | 480×234 |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A070SN02 V0 | AUO | 7.0 | 800×600 |
| A070VW01 V2 | AUO | 7.0 | 800×480 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| A070VW05 V1 | AUO | 7.0 | 800×480 |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| A070XN01 V0 | AUO | 7.0 | 1024×768 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| A070VW05 V1 | AUO | 7.0 | 800×480 |
| A070VW08 V2 | AUO | 7.0 | 800×480 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| HSD070IDW1-D00 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-E11 | HannStar | 7.0 | 800×480 |
| LA070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD02 | LG Display | 7.0 | 800×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| TX15D02VM0CAA | KOE | 5.8 | 400×240 |
