| Nama Wahi | A070SN02 V0 |
| Waitohu | AUO |
| Rahi | 7.0 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AUO |
| panel model | A070SN02 V0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800×600(RGB) , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 141.6×106.2 mm |
| outline | 154×119.2×5.08 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.2M (6-bit + Dithering), CIE193150% |
| response time | 4/16 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 3S6PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit) + SPI, 60 pins |
| input voltage | 3.3/5/-5/14/-14V (Typ.)(VDD/VDPA/VDNA/VGH/VGL) |
| application | DPF |
| A070SN01 V3 | AUO | 7.0 | 800×600 |
| A070SN02 V0 | AUO | 7.0 | 800×600 |
| A070SN02 V0 CELL | AUO | 7.0 | 800×600 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| EJ070NA-01J | Innolux | 7.0 | 1024×600 |
| HV070WS1-100 | HYDIS | 7.0 | 1024×600 |
| LTN070NL01-801 | Samsung | 7.0 | 1024×600 |
| LW700AT9901 | Innolux | 7.0 | 800×480 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| TM070DDH08 | Tianma | 7.0 | 1024×600 |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| HSD100IFW1-A02 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| LB070WV1-TD08 | LG Display | 7.0 | 800×480 |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
