| Nama Wahi | TM104SDHG30 |
| Waitohu | Tianma |
| Rahi | 10.4 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | TIANMA |
| panel model | TM104SDHG30 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.4 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 211.2×158.4 mm |
| outline | 228.4×175.4 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S12PWLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6/8-bit), 60 pins |
| input voltage | 3.3/11.0/21.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | DPF |
