| Nama Wahi | HSD084ISN1-A01 |
| Waitohu | HannStar |
| Rahi | 8.4 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 380 |
| CR | 600:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | HannStar |
| panel model | HSD084ISN1-A01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.4 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 170.4×127.8 mm |
| outline | 189.7×149.4×5.3 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 380 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 262K/16.2M (6-bit / 6-bit + FRC) |
| response time | 2/6 (Typ.)(Tr/Td) |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 3S9PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6/8-bit), 60 pins |
| input voltage | 3.3/10/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | DPF |
