| Nama Wahi | LB084S02-TD01 |
| Waitohu | LG Display |
| Rahi | 8.4 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | LG.Philips LCD |
| panel model | LB084S02-TD01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.4 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 170.4×127.8 mm |
| outline | 189.8×149.4 mm |
| surface | Antiglare |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit), CIE193146% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 65/65/45/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S9PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| input voltage | 3.3/10/19.5/-4.5/4.12V (Typ.)(VCC/AVDD/VGH/VGL/VCOM) |
| application | DPF |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| G084SN05 V8 | AUO | 8.4 | 800×600 |
| G084SN05 V9 | AUO | 8.4 | 800×600 |
| LB084S01-TL01 | LG Display | 8.4 | 800×600 |
| LB084S02-TD01 | LG Display | 8.4 | 800×600 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| LTM08C351 | TOSHIBA | 8.4 | 800×600 |
| MAA084DXA03 | Mitsubishi | 8.4 | 1024×768 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| LSA40AT9001 | Innolux | 10.4 | 800×600 |
| LTA120W1-T02 | Samsung | 12.0 | 800×480 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
