| Nama Wahi | LSA40AT9001 |
| Waitohu | Innolux |
| Rahi | 10.4 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | CHIMEI INNOLUX |
| panel model | LSA40AT9001 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.4 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 211.2×158.4 mm |
| outline | 228.4×175.4×6.2 mm |
| surface | Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S12PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6/8-bit), 60 pins |
| input voltage | 3.3/10.5V (Typ.)(VCC/AVDD) |
| application | DPF |
| A104SN01 V0 | AUO | 10.4 | 800×600 |
| AA104VC06 | Mitsubishi | 10.4 | 640×480 |
| G104SN02 V0 | AUO | 10.4 | 800×600 |
| LB104V03-A1 | LG Display | 10.4 | 640×480 |
| LM-EH53-22NTK | SANYO | 10.4 | 640×480 |
| LQ104V1DG11 | SHARP | 10.4 | 640×480 |
| LQ104V1DG21 | SHARP | 10.4 | 640×480 |
| LSA40AT9001 | Innolux | 10.4 | 800×600 |
| LTD104C11U | TOSHIBA | 10.4 | 640×480 |
| LTM10C348P | TOSHIBA | 10.4 | 800×600 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A104SN03 V1 | AUO | 10.4 | 800×600 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| HSD101PFW2-B01 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| LB070WV1-TD12 | LG Display | 7.0 | 800×480 |
| LQ070Y3DG02 | SHARP | 7.0 | 800×480 |
| LQ090Y3DG01A | SHARP | 9.0 | 800×480 |
| LTA070B0C0A | TOSHIBA | 7.0 | 480×234 |
| LW700AT9901 | Innolux | 7.0 | 800×480 |
