| Nama Wahi | HSD090LFW1-B00 |
| Waitohu | HannStar |
| Rahi | 9.0 |
| Taupānga | Automotive Display |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | HannStar |
| model | HSD090LFW1-B00 |
| diagonal size | 9.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×600 [WSVGA] 132PPI |
| configuration | RGB Vertical Stripe |
| active area | 196.608(H)×114.15(V) mm |
| outline dim. | 211.1(H)×126.5(V) ×6(D) mm |
| bezel area | 200.01(H)×117.55(V) mm |
| treatment | Glare (Haze 0%) |
| luminance | 450 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 17/18 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | IPS Pro, Normally Black, Transmissive |
| support color | 262K/16.2M 50% NTSC |
| light source | WLED , 150K hours , W/O Driver |
| weight | 230g (Typ.) |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| power supply | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
