| Nama Wahi | B070ATN01.0 |
| Waitohu | AUO |
| Rahi | 7.0 |
| Taupānga | DPF |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 700:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | B070ATN01.0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 153.6×90 mm |
| outline | 167.25×104.65×4.8 mm |
| surface | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% (Typ.) |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4S6PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 39 pins |
| input voltage | 3.3V (Typ.) |
| application | DPF |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| BA070WS1-401 | BOE | 7.0 | 1024×600 |
| BA070WS1-402 | BOE | 7.0 | 1024×600 |
| BP070WS1-500 | BOE | 7.0 | 1024×600 |
| CLAA070LFA1 CW | CPT | 7.0 | 800×480 |
| CLAA070WA03 | CPT | 7.0 | 480×234 |
| LA070WV6-SD01 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD01 | LG Display | 7.0 | 800×480 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| EJ080NA-05B | Innolux | 8.0 | 800×600 |
| HSD084ISN1-A01 | HannStar | 8.4 | 800×600 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LW700AT9901 | Innolux | 7.0 | 800×480 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
