| Nama Wahi | AT070TN01 |
| Waitohu | Innolux |
| Rahi | 7.0 |
| Taupānga | DPF |
| Whakatau | 480×234 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 300:1 |
| Nga Tae | Full color |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | INNOLUX |
| panel model | AT070TN01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 480(RGB)×234 |
| display mode | TN, Normally White, Transmissive |
| active area | 154.08×86.58 mm |
| outline | 164.9×100×6 mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | Full color |
| response time | 15/20 (Typ.)(Tr/Td) |
| viewing angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 26 pins |
| input voltage | 5.0/5.0/15.0/-10.0 (Typ.)(VCC/AVDD/VGH/VGL) |
| application | DPF |
