| Nama Wahi | TX31D50VM2BAA |
| Waitohu | KOE |
| Rahi | 12.0 |
| Taupānga | DPF |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 350:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | HITACHI |
| panel model | TX31D50VM2BAA |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 261.6×156.96 mm |
| outline | 283×173.8 mm |
| surface | |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) |
| display colors | 262K (6-bit), CIE193170% |
| response time | |
| viewing angle | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 1 pcsCCFL |
| signal interface | CMOS (1 ch, 6-bit) |
| input voltage | 3.3V (Typ.) |
| rohs: | |
| application | DPF |
