| Nama Wahi | TM047XDZP02 |
| Waitohu | Tianma |
| Rahi | 4.7 |
| Taupānga | MPH |
| Whakatau | 540×960 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | TIANMA |
| panel model | TM047XDZP02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.7 inch |
| resolution | 540(RGB)×960 , qHD |
| display mode | SFT, Normally Black, Transmissive |
| active area | 58.32×103.68 mm |
| outline | 62.72×113.53×1.78 mm |
| surface | |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193170% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S2PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 24 pins |
| input voltage | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| application | MPH |
