| Nama Wahi | TM047NBH01 |
| Waitohu | Tianma |
| Rahi | 4.7 |
| Taupānga | PND |
| Whakatau | 480×272 |
| Te tito | LCM |
| Tirohanga | 280 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | TIANMA |
| panel model | TM047NBH01 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.7 inch |
| resolution | 480(RGB)×272 , WQVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 103.68×58.752 mm |
| outline | 114.3×72.5 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 280 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 45 pins |
| input voltage | 3.3V (Typ.) |
| application | PND |
