| Nama Wahi | LMS430HF20 |
| Waitohu | Samsung |
| Rahi | 4.3 |
| Taupānga | PND |
| Whakatau | 480×272 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LMS430HF20 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.3 inch |
| resolution | 480×272(RGB) , WQVGA |
| display mode | VA, Normally Black, TMR |
| active area | 95.04×53.856 mm |
| outline | 105.5×67.2 mm |
| surface | |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 900 : 1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 17/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 10S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| input voltage | 2.5/3.3V (Typ.)(VDD) |
| application | PND |
