| Nama Wahi | LMS430HF27 |
| Waitohu | Samsung |
| Rahi | 4.3 |
| Taupānga | PND |
| Whakatau | 480×272 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LMS430HF27 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.3 inch |
| resolution | 480×272(RGB) , WQVGA |
| display mode | VA, Normally Black, Transflective |
| active area | 95.04×53.856 mm |
| outline | 105.5×67.2 mm |
| surface | |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.)(Transmissive) |
| display colors | 16.7M (8-bit) |
| response time | 17/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 10S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| input voltage | 3.3V (Typ.) |
| application | PND |
| LMS430HF01 | Samsung | 4.3 | |
| LMS430HF01-013 | Samsung | 4.3 | |
| LMS430HF02 | Samsung | 4.3 | 480×272 |
| LMS430HF11 | Samsung | 4.3 | 480×272 |
| LMS430HF11-003 | Samsung | 4.3 | 480×272 |
| LMS430HF12-003 | Samsung | 4.3 | 480×272 |
| LMS430HF17-002 | Samsung | 4.3 | 480×272 |
| LMS430HF18 | Samsung | 4.3 | 480×272 |
| LMS430HF19 | Samsung | 4.3 | 480×272 |
| LMS430HF27 | Samsung | 4.3 | 480×272 |
| 43WQW1H | SII | 4.3 | 480×272 |
| A047FW01 V0 | AUO | 4.7 | 480×272 |
| AT043TN25 V.1 | Innolux | 4.3 | 480×272 |
| AT050TN33 V.1 | Innolux | 5.0 | 480×272 |
| LMS430HF26 | Samsung | 4.3 | 480×272 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| PD035VX2 | E Ink | 3.5 | 640×480 |
| TM043NDH02 | Tianma | 4.3 | 480×272 |
