| Nama Wahi | TM047NDH01 |
| Waitohu | Tianma |
| Rahi | 4.7 |
| Taupānga | PND |
| Whakatau | 480×272 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 400:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | TIANMA |
| panel model | TM047NDH01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.7 inch |
| resolution | 480(RGB)×272 , WQVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 103.68×58.752 mm |
| outline | 114.3×72.5 mm |
| surface | Clear, Hard coating (3H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S1P+6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 45 pins |
| input voltage | 3.3V (Typ.) |
| application | PND |
| 990000475 | TPO | 4.3 | 800×480 |
| 990000475P | TPO | 4.3 | 800×480 |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| DLC0430LZG-T | Other | 4.3 | 480×272 |
| LMS480KC02 | Samsung | 4.8 | 800×480 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LQ043T1DH41 | SHARP | 4.3 | 480×272 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
