| Nama Wahi | LW850AT9301 |
| Waitohu | Innolux |
| Rahi | 8.5 |
| Taupānga | DPF |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 270 |
| CR | 300:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | CHIMEI INNOLUX |
| panel model | LW850AT9301 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.5 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 184.8×110.88 mm |
| outline | 206.1×124.48×8.5 mm |
| surface | Antiglare (Haze 25%) |
| brightness | 270 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193150% |
| response time | 15/35 (Typ.)(Tr/Td) |
| viewing angle | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| input voltage | 3.3V (Typ.)(VCC) |
| application | DPF |
