| Nama Wahi | LQ085Y3DW01 |
| Waitohu | SHARP |
| Rahi | 8.5 |
| Taupānga | IA |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ085Y3DW01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.5 inch |
| resolution | 800×480(RGB) , WVGA |
| display mode | ASV, Normally Black, Transmissive |
| active area | 184.8×110.88 mm |
| outline | 210×134 mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 9S4PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| EL640.480-AAA | PLANAR | 10.4 | 640×480 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| G065VN01 V1 | AUO | 6.5 | 640×480 |
| LM641836 | SHARP | 9.4 | 640×480 |
| NL6448BC26-11 | NLT | 8.4 | 640×480 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
| TCG035QVLPDANN-GN50 | Kyocera | 3.5 | 320×240 |
| TX18D30VM2FAA | KOE | 7.0 | 800×480 |
| UG-2864ASYDT01 | WiseChip | 2.7 | 128×64 |
| UG-9664HDDAG01 | WiseChip | 0.95 | 96×64 |
