| Nama Wahi | HSD070ISN1-D00 |
| Waitohu | HannStar |
| Rahi | 7.0 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | HannStar |
| panel model | HSD070ISN1-D00 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 141.6×106.2 mm |
| outline | 156.4×122.25×4.4 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193150% |
| response time | 2.4/5.6 (Typ.)(Tr/Td) |
| viewing angle | 60/70/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2S5PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 60 pins |
| input voltage | 3.3/9.5/16.5/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | DPF |
