| Nama Wahi | C090EAN04.1 |
| Waitohu | AUO |
| Rahi | 9.0 |
| Taupānga | Outdoor High Brightn |
| Whakatau | 1280×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | AUO |
| model | C090EAN04.1 |
| diagonal size | 9.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×720 [WXGA] 163PPI |
| configuration | RGB Vertical Stripe |
| active area | 198.72(H)×111.78(V) mm |
| outline dim. | 212.2(H)×127.9(V) ×11(D) mm |
| bezel area | 202.02(H)×115.78(V) mm |
| treatment | Antiglare |
| luminance | 900 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| operating mode | AHVA, Normally Black, Transmissive |
| support color | 16.7M 72% NTSC |
| light source | WLED [8S3P] , 10K hours , W/O Driver |
| weight | TBD |
| designed for | Outdoor High Brightness Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | LVDS (1 ch, 8-bit) , 40 pins FPC |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
