| Nama Wahi | TX23D12VM0CAA |
| Waitohu | KOE |
| Rahi | 9.0 |
| Taupānga | IA |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | HITACHI |
| panel model | TX23D12VM0CAA |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 195×117 mm |
| outline | 236×135 mm |
| surface | Antiglare |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit), CIE193160% |
| response time | 13/17 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.)(VDD) |
| application | IA |
