Nama Wahi | M150MNN1 R1 |
Waitohu | IVO |
Rahi | 15.0 |
Taupānga | IA |
Whakatau | 1024×768 |
Te tito | LCM |
Tirohanga | 350 |
CR | 800:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | LVDS |
panel brand | IVO |
panel model | M150MNN1 R1 1 Compatible model |
panel type | a-Si TFT-LCD , LCM |
panel size | 15.0 inch |
resolution | 1024(RGB)×768 , XGA |
display mode | TN, Normally White, Transmissive |
active area | 304.128×228.096 mm |
outline | 326.5×253.5×10.1 mm |
surface | Antiglare, Hard coating (3H) |
brightness | 350 cd/m² (Typ.) |
contrast ratio | 800:1 (Typ.) |
display colors | 16.7M (8-bit), CIE193155% |
response time | 6/24 (Typ.)(Tr/Td) |
viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
lamp type | WLEDEmbedded (LED Driver) |
signal interface | LVDS (1 ch, 8-bit), 20 pins |
input voltage | 3.3V (Typ.) |
application | IA |
