| Nama Wahi | BP101WX1-400 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | PAD |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | BOE |
| panel model | BP101WX1-400 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.1 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | ADS, Normally Black, Transmissive |
| active area | 216.96×135.6 mm |
| outline | 229.46×149.15×4.5 mm |
| surface | Antiglare, Antireflection |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193150% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | MIPI (4 data lanes), 40 pins |
| input voltage | 3.7V (Typ.) |
| application | PAD |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| HSD101PFW1-B00 | HannStar | 10.1 | 1024×576 |
| LP101WH1-TLA3 | LG Display | 10.1 | 1366×768 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| BP096WX1-100 | BOE | 9.6 | 800×1280 |
| CLAA070NQ01 XN | CPT | 7.0 | 1024×600 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| LTL101AL06-003 | Samsung | 10.1 | 1280×800 |
