| Nama Wahi | BP096WX1-100 |
| Waitohu | BOE |
| Rahi | 9.6 |
| Taupānga | PAD |
| Whakatau | 800×1280 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | BOE |
| panel model | BP096WX1-100 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.6 inch |
| resolution | 800(RGB)×1280 , WXGA |
| display mode | ADS, Normally Black, Transmissive |
| active area | 129×206.4 mm |
| outline | 136.8×217.1×4.2 mm |
| surface | Antiglare (Haze 3.1%) |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 20/20 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S4PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 45 pins |
| input voltage | 1.8/3.7V (Typ.)(VDD/VDDI) |
| application | PAD |
