| Nama Wahi | AM-240320GTZQW-02H |
| Waitohu | AMPIRE |
| Rahi | 2.8 |
| Taupānga | Mobile Phone |
| Whakatau | 240×320 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 450:1 |
| Nga Tae | 65K |
| Whakamuri | WLED |
| Atanga | CPU/RGB/SPI |
| brand | AMPIRE |
| model | AM-240320GTZQW-02H |
| diagonal size | 2.8 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 240(RGB)×320 [QVGA] 141PPI |
| configuration | RGB Vertical Stripe |
| active area | 43.2(H)×57.6(V) mm |
| outline dim. | 49(H)×67.5(V) ×4.9(D) mm |
| luminance | 280 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 15/20 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| operating mode | MVA, Normally Black, Transmissive |
| support color | 65K 69% NTSC |
| light source | WLED [3S2P] , With LED Driver |
| weight | TBD |
| designed for | Mobile Phone |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | CPU/RGB/SPI , 40 pins FPC |
| power supply | 2.8V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
