| Nama Wahi | AM-240320-024DT |
| Waitohu | Other |
| Rahi | 2.4 |
| Taupānga | HHP |
| Whakatau | 240×320 |
| Te tito | LCM |
| Tirohanga | |
| CR | |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | CPU |
| panel brand | Amson |
| panel model | AM-240320-024DT |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.4 inch |
| resolution | 240(RGB)×320 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 36.72×48.96 mm |
| outline | 42.72×60.26×3.8 mm |
| surface | |
| brightness | |
| contrast ratio | |
| display colors | 262K |
| response time | |
| viewing angle | |
| lamp type | 4 stringsWLEDWithout Driver |
| signal interface | 8/16-bit 8080 parallel, 40 pins |
| input voltage | 2.8/2.8V (Typ.)(IOVCC/VCI) |
| application | HHP |
