| Nama Wahi | TM028LDZ09 |
| Waitohu | Tianma |
| Rahi | 2.8 |
| Taupānga | MPH |
| Whakatau | 240×400 |
| Te tito | LCM |
| Tirohanga | 240 |
| CR | 450:1 |
| Nga Tae | 65K/262K |
| Whakamuri | WLED |
| Atanga | CPU |
| panel brand | TIANMA |
| panel model | TM028LDZ09 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.8 inch |
| resolution | 240(RGB)×400 , WQVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 36.72×61.2 mm |
| outline | 42×72.8 mm |
| surface | |
| brightness | 240 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) |
| display colors | 65K/262K , CIE193156% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1S4PWLEDWithout Driver |
| signal interface | CPU, 39 pins |
| input voltage | (1.8/2.8)/2.8V (Typ.)(VDDIO/VDD) |
| application | MPH |
