| Nama Wahi | TFT240320-237-E |
| Waitohu | Other |
| Rahi | 2.8 |
| Taupānga | MPH |
| Whakatau | 240×320 |
| Te tito | LCM |
| Tirohanga | 125 |
| CR | 95:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | CPU/RGB/SPI |
| panel brand | TRULY |
| panel model | TFT240320-237-E |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.8 inch |
| resolution | 240(RGB)×320 , QVGA |
| display mode | TN, Normally White, Transflective |
| active area | 43.2×57.6 mm |
| outline | 50×69.2 mm |
| surface | |
| brightness | 125 cd/m² (Typ.) |
| contrast ratio | 95:1 (Typ.)(Transmissive)3.5:1 (Typ.)(Reflective) |
| display colors | 262K |
| response time | 32.8 (Typ.)(Tr+Td) |
| viewing angle | 45/45/41/32 (Typ.)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1S4PWLEDWithout Driver |
| signal interface | CPU/RGB/SPI, 47 pins |
| input voltage | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| application | MPH |
