| Nama Wahi | LTV280QV-F02 |
| Waitohu | Samsung |
| Rahi | 2.8 |
| Taupānga | DVC |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 250:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LTV280QV-F02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.8 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 61.44×34.32 mm |
| outline | 68.41×45.23×2.97 mm |
| surface | |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 250:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 75Hz |
| lamp type | 4S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 64 pins |
| input voltage | 3.3V (Typ.) |
| application | DVC |
