| Nama Wahi | A035VL01 V3 |
| Waitohu | AUO |
| Rahi | 3.5 |
| Taupānga | DVC |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 315 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AUO |
| panel model | A035VL01 V3 |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 3.5 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 75.6×45.36 mm |
| outline | 86.1×51.66 mm |
| surface | Glare (Haze 0%) |
| brightness | 315 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 15/30 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| input voltage | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| application | DVC |
