| Nama Wahi | AM-1024600Y3TZQW-A0H |
| Waitohu | AMPIRE |
| Rahi | 9.0 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel model | AM-1024600Y3TZQW-A0H |
| panel size | 9.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1024(RGB)×600, WSVGA, 132PPI |
| pixel format | RGB Vertical Stripe |
| display area | 196.6(W)×114.1(H) mm |
| bezel opening | 200(W)×117.55(H) mm |
| outline size | 211.1(W)×126.5(H) ×11(D) mm |
| surface | - |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 18/17 (Typ.)(Tr/Td) |
| display colors | 16.7M |
| lamp type | WLED , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | TBD |
| application | Industrial |
| signal interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
