| Nama Wahi | AM-1024600L7TMQW-T05H |
| Waitohu | AMPIRE |
| Rahi | 10.1 |
| Taupānga | IA |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 440 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel model | AM-1024600L7TMQW-T05H |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.1 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 222.72×125.28 mm |
| outline | 235×145.8×10.3 mm |
| surface | |
| brightness | 440 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 5/20 (Typ.)(Tr/Td) |
| viewing angle | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 6S6PWLEDOptional |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
