| Nama Wahi | AM-1024600KTMQW-04H |
| Waitohu | AMPIRE |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 1000 |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel model | AM-1024600KTMQW-04H |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 153.6×90 mm |
| outline | 165.5×104.44×5.3 mm |
| surface | Glare (Haze 0%), Hard coating |
| brightness | 1000 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8S3PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 39 pins |
| input voltage | 3.3V (Typ.) |
| application | CNS |
