| Nama Wahi | TV080WXM-NS1 |
| Waitohu | BOE |
| Rahi | 8.0 |
| Taupānga | Pad & Tablet |
| Whakatau | 800×1280 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1100:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| brand | BOE |
| diagonal size | 8.0 inch |
| pixel format | 800(RGB)×1280 [WXGA] 188PPI |
| active area | 107.64(H)×172.224(V) mm |
| luminance | 530 cd/m² (Typ.) |
| view direction | Symmetry |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| support color | 16.7M 87% NTSC |
| weight | - |
| frame rate | 60Hz |
| interface type | MIPI (4 data lanes) , 34 pins Connector |
| power supply | 1.8/5.4/-5.4V (Typ.)(VDD1/PVDD/NVDD) |
| environment | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TV080WXM-NS1 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 114.65(H)×183.853(V) ×3.56(D) mm |
| contrast ratio | 1100:1 (Typ.) (TM) |
| response time | 30 (Typ.)(Tr+Td) |
| operating mode | ADS, Normally Black, Transmissive |
| light source | WLED [3 strings] , W/O Driver |
| designed for | Pad & Tablet |
| touch panel | Without |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LT080EE04100 | TOSHIBA | 8.0 | 1600×768 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| PD080SL1 | E Ink | 8.0 | 800×600 |
| PD080SL5 | E Ink | 8.0 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TV080WXM-NL0 | BOE | 8.0 | 800×1280 |
