| Nama Wahi | PD080SL1 |
| Waitohu | E Ink |
| Rahi | 8.0 |
| Taupānga | IA |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 420 |
| CR | 400:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | PVI |
| panel model | PD080SL1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 200×152×10.8 mm |
| surface | Antiglare |
| brightness | 420 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| response time | 15/25 (Typ.)(Tr/Td) |
| viewing angle | 60/60/35/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| EK08009-70235 | Other | 8.0 | 800×600 |
| LB080WV4-TD02 | LG Display | 8.0 | 800×480 |
| LM64P122 | SHARP | 8.0 | 640×480 |
| PD080SL1 | E Ink | 8.0 | 800×600 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| PD080SL3 | E Ink | 8.0 | 800×600 |
| PD080SL5 | E Ink | 8.0 | 800×600 |
| PD080SY1 | E Ink | 8.0 | 800×600 |
| AA070MC11 | Mitsubishi | 7.0 | 800×480 |
| G050VTN01.1 | AUO | 5.0 | 800×480 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| LB121S03-TL04 | LG Display | 12.1 | 800×600 |
| LM057QC1T01 | SHARP | 5.7 | 320×240 |
| LM12S471 | SHARP | 12.1 | 800×600 |
| LQ104V1DG5B | SHARP | 10.4 | 640×480 |
| LTA121C32HF | TOSHIBA | 12.1 | 800×600 |
| MD286TT00-C1 | ORTUSTECH | 10.4 | 640×480 |
| TX18D37VM0AQA | KOE | 7.0 | 800×480 |
