| Nama Wahi | TM080RBHG30 |
| Waitohu | TIANMA |
| Rahi | 8.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 3S12P |
| Atanga | |
| manufacturer | TIANMA |
| model name | TM080RBHG30 |
| screen size | 8.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 116PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 176.64 × 99.36 (H×V) |
| outline(mm) | 192.8 × 116.9 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 375 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K/16.7M 65% NTSC |
| backlight | 3S12P WLED , 20K hours , No Driver |
| mass | 280g (Typ.) |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
