| Nama Wahi | TM080SDH01 |
| Waitohu | Tianma |
| Rahi | 8.0 |
| Taupānga | IA |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AVIC |
| panel model | TM080SDH01 2 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 183×141×5.9 mm |
| surface | Antiglare |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S9PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6/8-bit), 50 pins |
| input voltage | 3.3/12.5/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | IA |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| DJ080PA-01C | Innolux | 8.0 | |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| TM080SV-04L01 | SANYO | 8.0 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
| AA057QD01 | Mitsubishi | 5.7 | 320×240 |
| G190SVT01.0 | AUO | 19.0 | 1680×342 |
| KCS057QV1AJ-G20 | Kyocera | 5.7 | 320×240 |
| LCBHBT161M | NAN YA | 5.7 | 320×240 |
| LM10V332R | SHARP | 10.4 | 640×480 |
| LQ085Y3DG18 | SHARP | 8.5 | 800×480 |
| NL10276BC30-34D | NLT | 15.0 | 1024×768 |
| RGS08096032WR001 | RiTdisplay | 0.80 | 96×32 |
| SX19V007-Z2A | KOE | 7.5 | 640×480 |
| TX17D200VM0BAA | KOE | 6.5 | 800×480 |
