| Nama Wahi | S101WS07 |
| Waitohu | CDTECH |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | 3S6P |
| Atanga | Parallel |
| manufacturer | CDTECH |
| screen size | 10.1 inch |
| pixel number | 1024(RGB)×600 (WSVGA) 117PPI |
| active area(mm) | 222.72 × 125.28 (H×V) |
| bezel area(mm) | 226.34 × 128.1 (H×V) |
| luminance | 200 cd/m² (Typ.) |
| viewing angle | 65/65/55/65 (Typ.)(CR≥10) |
| good view at | 12 o'clock |
| color depth | 16.7M |
| mass | TBD |
| refresh rate | 60Hz |
| signal type | Parallel RGB (1 ch, 8-bit) , 50 pins FPC |
| voltage supply | 3.3/10.85/21/-5.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | S101WS07 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 235 × 143 × 5.39 (H×V×D) |
| treatment | - |
| contrast ratio | 600 : 1 (Typ.) (TM) |
| response | 6/20 (Typ.)(Tr/Td) ms |
| work mode | TN, Normally White, Transmissive |
| backlight | 3S6P WLED , 25K hours , No Driver |
| used for | Industrial |
| touchscreen | Without |
