| Nama Wahi | PM102ZY2 |
| Waitohu | E Ink |
| Rahi | 10.2 |
| Taupānga | DPF |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 600:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL/RSDS |
| panel brand | PVI |
| panel model | PM102ZY2 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.2 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 222.72×130.5 mm |
| outline | 235×145.8×6.5 mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 15/25 (Typ.)(Tr/Td) |
| viewing angle | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | TTL/RSDS (1 ch, 6-bit), 60 pins |
| input voltage | 3.3/3.3/9.1/17.0/-5.6V (Typ.)(VCC/VDD1/VDD2/VGG/VEE) |
| application | DPF |
