| Nama Wahi | NL10276AC30-07 |
| Waitohu | NLT |
| Rahi | 15.0 |
| Taupānga | DMPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 300:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | NEC |
| panel model | NL10276AC30-07 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.0 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | Normally Black, Transmissive |
| active area | 304.128×228.096 mm |
| outline | 330×256×30 mm |
| surface | Hard coating (2H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193160% |
| response time | 10/10 (Typ.)(Tr/Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8 pcsCCFLEmbedded (Inverter) |
| signal interface | TTL (2 ch, 8-bit), 75 pins |
| input voltage | 5.0V (Typ.) |
| application | DMPC |
