| Nama Wahi | NL10276AC24-05 |
| Waitohu | NLT |
| Rahi | 12.1 |
| Taupānga | DMPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 150:1 |
| Nga Tae | Full color |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | NEC |
| panel model | NL10276AC24-05 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 245.76×184.32 mm |
| outline | 290×225×17 mm |
| surface | |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 150:1 (Typ.) |
| display colors | Full color , CIE193140% |
| response time | 40 (Max.)(Tr) |
| viewing angle | 50/50/20/20 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 2 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB, 31 pins |
| input voltage | 3.3/12V (Typ.)(VCC/VDD) |
| application | DMPC |
